Stackable battery pack

$0.00 USD

Sale Inquiry

Easy installation:

Stacked installation can be operated by one person

Safety protection function:

Real-time monitoring of battery cell voltage, current and temperature , three-level fault warning and multiple software and hardware protection

Strong scalability:

Expanded to 2~10 battery packs according to the matching inverter and actual usage

Overcharge and over-discharge protection:

Internally use contactor switch , reliable switch ;over-discharge system automatically cuts off power to reduce self-loss

Passive balancing:

Balance battery voltage difference to extend battery pack life

High-precision acquisition:

Battery cell sampling accuracy +3mv

𝐍𝐨𝐭𝐞:Our shipping is via 𝐬𝐞𝐚 𝐟𝐫𝐞𝐢𝐠𝐡𝐭, with a transit time of approximately 𝟔𝟎 days. If air freight is required, please click the "Chat" button to contact us, or reach out via Phone number: 400-900-9536 / Email: info@koyoe.com

Series use
High safety
Long cycle life

KY-51V100AH-01

View full details

Technical parameter

Battery cell

Battery cell type Li-ion(LFP)Lithium lron Phosphate
Capacity(Ah) 100
Battery cell grouping method 1P16S

Battery parameters

Rated voltage (V) 51.2
Rated capacity(A) 100
Rated energy (wh) 5120
Discharge depth (%) 90
Working voltage range (V) 44.8~58.4
Rated current (A) 50

Basic PACK parameters

Dimensions (W*H*D)(mm) 580*193*390
Communication method SPI daisy chain
Operating temperature (°C) Charging 0~55 Discharging -20~60
Storage temperature (°C) 0~45
Humidity (%) 0~95
Altitude (m) <2000
