Support multiple battery protocols Support 6 machines in parallel, constitute three-phase four-wire power generation system High precision MPPT controller The battery has a balanced charging mode If the photovoltaic power is insufficient, the photovoltaic can be combined with the power grid and battery to supply the load Battery can use PV maximum to input voltage 500Vdc or not use lt has a power-saving mode function to reduce no-load loss Economic model can be used to charge and discharge the inverter Monitoring system WIFI/GPRS option Adopt an intelligent adjustable-speed fan for efficient heatdissipation and prolong the service life of the system
ππ¨ππ:Our shipping is viaΒ π¬ππ ππ«ππ’π π‘π, with a transit time of approximately ππ days.Β If air freight is required, please click the "Chat" button to contact us, or reach out via Phone number: 400-900-9536 / Email: info@koyoe.com
Maximum PV Input Power 5500W
MPPT Range @ Operating Voltage 120VDC - 450VDC
Maximum PV Input Current 22A
Number of Independent MPP Trackers/Strings Per MPP Tracker 1/2
Maximum PV Open-circuit Voltage 500VDC
Maximum Solar Charge Current 100A
Battery Data
Battery Voltage 48VDC
Hybrid Charging Maximum Charging Current 100A
Battery Type Lithium/Lead-acid
AC Data(Off-grid Interface)
Rated Power 5000VA/5000W
Parallel Capability YesοΌ6 units maximum
AC Voltage Regulation 120VAC Β± 5% @ 50/60Hz
Surge Power 10000VA
Efficiency (Peak) 93%
Waveform Pure sine wave
Transfer Time 10ms typical, 20ms Max
Certification
UL1741/FCC
