Adopt DSP full digital control mode If the photovoltaic power is insufficient, the photovoltaic can be combined with the power grid and battery to supply the load High precision MPPT controller The battery has a balanced charging mode Battery can use PV maximum to input voltage 500Vdc or not use Both are configured the grid and PV prioritize Monitoring system WIFI/GPRS option Economic model can be used to charge and discharge the inverter Power grid and oil machine can be freely selected
ππ¨ππ:Our shipping is viaΒ π¬ππ ππ«ππ’π π‘π, with a transit time of approximately ππ days.Β If air freight is required, please click the "Chat" button to contact us, or reach out via Phone number: 400-900-9536 / Email: info@koyoe.com
Maximum PV Input Power 4000W
MPPT Range @ Operating Voltage 120VDC - 450VDC
Maximum PV Input Current 13A
Number of Independent MPP Trackers/Strings Per MPP Tracker 1/1
Maximum PV Open-circuit Voltage 500VDC
Maximum Solar Charge Current 80A
Battery Data
Battery Voltage 24VDC
Hybrid Charging Maximum Charging Current 80A
Battery Type Lithium/Lead-acid
AC Data(Off-grid Interface)
Rated Power 3600VA
Parallel Capability NO
AC Voltage Regulation 230VAC Β± 5% @ 50/60Hz
Surge Power 6000VA
Efficiency (Peak) 93%
Waveform Pure sine wave
Transfer Time 10ms typical, 20ms Max
Certification
IEC62109-1/2,
EN61000-6-1/3
