High-performance dual digital signal DSP control Dual independent MPPT inputs, 2x PV input power Time-of-use charging and discharging PV input with ISO array insulation resistance detection AC output with GFCI (Ground Fault Circuit Interrupter) current detection Support 6 machines in parallel If the photovoltaic power is insuffi cient, the photovoltaic can be combined with the power grid and battery to supply the load Capable of handling unbalanced loads Multiple lithium battery activation functions Equipped with 485/CAN communication interfaces
ππ¨ππ:Our shipping is viaΒ π¬ππ ππ«ππ’π π‘π, with a transit time of approximately ππ days.Β If air freight is required, please click the "Chat" button to contact us, or reach out via Phone number: 400-900-9536 / Email: info@koyoe.com
Maximum PV Input Power 2*9000W
MPPT Range @ Operating Voltage 200VDC - 650VDC
Maximum PV Input Current 2*22A
Number of Independent MPP Trackers/Strings Per MPP Tracker 2/2
Maximum PV Open-circuit Voltage 800VDC
Maximum Solar Charge Current 260A
Battery Data
Battery Voltage 48VDC
Hybrid Charging Maximum Charging Current 260A
Battery Type Lithium/Lead-acid
AC Data(Off-grid Interface)
Rated Power 12000VA/12000W
Parallel Capability YesοΌ6 units maximum
AC Voltage Regulation 230/400VAC 3P Β± 5% @ 50/60Hz
Surge Power 24000VA
Efficiency (Peak) 93%
Waveform Pure sine wave
Transfer Time 10ms typical, 20ms Max
Certification
IEC62109-1/2,
EN61000-6-1/3
