Support carp-ion battery BMS communication Support 6 machines in parallel, constitute three-phase four-wire power generation system 2 high-efficiency, independent MPPT ports If the photovoltaic power is insufficient, the photovoltaic can be combined with the power grid and battery to supply the load Battery can use PV maximum to input voltage 500Vdc or not use Both are configured the grid and PV prioritize Economic model can be used to charge and discharge the inverter Load power up to 10 kilowatts Power grid and oil machine can be freely selected
ππ¨ππ:Our shipping is viaΒ π¬ππ ππ«ππ’π π‘π, with a transit time of approximately ππ days.Β If air freight is required, please click the "Chat" button to contact us, or reach out via Phone number: 400-900-9536 / Email: info@koyoe.com
Maximum PV Input Power 2*5500W
MPPT Range @ Operating Voltage 120VDC - 450VDC
Maximum PV Input Current 2*22A
Number of Independent MPP Trackers/Strings Per MPP Tracker 2/2
Maximum PV Open-circuit Voltage 500VDC
Maximum Solar Charge Current 200A
Battery Data
Battery Voltage 48VDC
Hybrid Charging Maximum Charging Current 200A
Battery Type Lithium/Lead-acid
AC Data(Off-grid Interface)
Rated Power 10000VA/10000W
Parallel Capability YesοΌ6 units maximum
AC Voltage Regulation 230VAC Β± 5% @ 50/60Hz
Surge Power 20000VA
Efficiency (Peak) 93%
Waveform Pure sine wave
Transfer Time 10ms typical, 20ms Max
Certification
IEC62109-1/2,
EN61000-6-1/3
